High Luminance Samsung LCD Display , 3.5 Inch A - Si TFT - LCD Panel LTP350QV-E09 With Panel Signal Interface

N&S ELECTRONIC CO., LIMITED
Contact Now

High Luminance Samsung LCD Display , 3.5 Inch A - Si TFT - LCD Panel LTP350QV-E09 With Panel Signal Interface

Brand Name : Samsung

Model Number : LTP350QV-E09

Certification : ISO9001

Place of Origin : Korea

MOQ : 1 Piece

Payment Terms : T/T, Paypal, Western Union, MoneyGram

Supply Ability : 100 PCS / DAY

Delivery Time : 2-3 working days after payment confirmation

Packaging Details : Antistatic bag, Bubble Bag, Foam Box and Carton Box.

Panel Model : LTP350QV-E09

Display Mode : TN, Normally White, Transflective

Panel Type : a-Si TFT-LCD , Panel

Panel Size : 3.5 inch

Form Factor : Flat Rectangle Display

Panel Brand : SAMSUNG

Contact Now

Samsung LCD Panel , 3.5 inch LCD LTP350QV-E09 Hard a-Si TFT-LCD VGA Panel

Quick Details About LTP350QV-E09 :

<

1. Resolution : 1024(RGB)×600 , WSVGA
2. Display Mode : TN, Normally White, Transmissive
3. Active Area : 222.72×125.28 mm
4. Outline : 245×146.5×3.6 mm
5. Brightness : 200 cd/m² (Typ.)
6. Shape Style : Flat (PCBA Flat, Depth 3.4~4.0mm)
7. Surface : Glare (Haze 0%), Hard coating (3H)

Technical parameters for Samsung LTP350QV-E09:

<<

Lamp Position : Edge light type
Lamp Type : WLED
Lamp Amount : 8S2P
Lamp Shape : Array
Lamp Life Time : 10K(Min.) (Hours)
Lamp Voltage : 25.6V (Typ.)
Lamp Current : 61.5mA (Typ.)
Lamps Power Consumption : 1.74/2.05W (Typ./Max.)
Interface Type : Included in panel signal interface
Lamp Driver Board : Embedded (LED Driver)
Lamp Driver Board : 5.0/12.0/21.0V (Min./Typ./Max.)
Lamp Driver Board : 170mA (Typ.)
Lamp Driver Board : 2.04W (Typ.)

Box Gross Weight : 7 Kgs

Delivery time is approx:

United States / United Kingdom / Australia 7-14 working days.

Canada 7-25 working days.

France / Spain / Germany may take 7-20 working days.

Eastern Europe may take up to 16-30 working days.

Italy / Brazil / South America may take up to 30-50 working days.

Shipped by DHL Express (Need 3-6 working days to arrive)

About Shipping:

We will test them strictly before shipping.

We will ship it in 1-3 working days after your paying.

We only ship according to the shipping address,if you want to change shipping address,pls contact me in advance in time.as to the shipping time,it usually will be 7-30 days,which will be

different for different countries.

Some pictures about Samsung LTP350QV-E09 :

High Luminance Samsung LCD Display , 3.5 Inch A - Si TFT - LCD Panel LTP350QV-E09 With Panel Signal Interface
